The back of our APC Smart-UPS 2000 has a USB port so that it can be monitored from a server it supplies.

However, this USB port doesn't appear to be a standard USB connector. It looks a little like an RJ-45 connector, I tried an Ethernet cable in case the port was just mislabeled but that didn't fit either.

Strange USB port

Can anyone help identify the type of USB it is?

Mokubai
  • 89,133
  • 25
  • 207
  • 233
Burgi
  • 6,493
  • 14
  • 39
  • 52
  • 21
    FWIW, if you are looking to buy new APC UPS units, the company has done something completely “crazy” and now that port is a standard USB port. Why it was this thing for years is baffling. Wonder if it was something connected to licensing or the USB standard and power supplies. – Giacomo1968 Dec 05 '17 at 15:37
  • 8
    @JakeGould It's likely a legacy format rather than a licensing issue. RJ-45 connectors for serial ports have been around a long time. I know as recently as 2010 I had Cisco gear on my desk that used an RJ-45 to serial adapter to get a console connection. This question should help clarify https://serverfault.com/questions/629436/why-is-rj45-db9-console-cable-still-used-when-all-the-latest-computer-do-not-ha – Freiheit Dec 05 '17 at 19:05
  • @Freiheit You know, you might be right. Back in 1991-1992 I had an [AST Premium Exec 383SX/20 notebook computer](http://www.computinghistory.org.uk/det/2230/ast-386sx-20-notebook/) that had an option for a modem or a serial port and the serial port was and RJ-45 port. – Giacomo1968 Dec 05 '17 at 20:48
  • 32
    Technically that *is* an RJ-45. It just happens to be wired for USB instead of Ethernet. – chrylis -cautiouslyoptimistic- Dec 05 '17 at 22:45
  • 9
    I bet someone got a really nice bonus for that feature. (To quote Raymond Chen) – user253751 Dec 06 '17 at 01:14
  • 2
    FWIW, I was trying to look up some specs if you wanted to “roll your own” cable and [found this cheap custom USB to APC UPS DataPort cable](http://www.obsoletelab.com/index.php?main_page=product_info&cPath=8_11&products_id=32&zenid=5ljtjamdt7mmmp34edtasg4216) this place called “Obsolete Laboratory” is selling. And also found [a good discussion—with pinouts—on how to make your own APC USB to RJ-45 UPS cable](http://www.hardwarecanucks.com/forum/guides-how-tos/17082-how-build-apc-u-p-s-data-cable-2.html). – Giacomo1968 Dec 06 '17 at 02:32
  • 8
    Fun fact : USB male fit into a RJ45 slot. So when our user says "yeah I plugged it in" don't trust him... – Goufalite Dec 06 '17 at 08:15
  • 1
    @Freiheit: For console cables, RJ-45 might be quite intentional since a [rollover cable](https://en.wikipedia.org/wiki/Rollover_cable) greatly simplifies serial connections (no need to distinguish between regular and null-modem cables or use DTE/DCE gender changers, and of course no need for a massive DB-9 port). – u1686_grawity Dec 06 '17 at 08:42
  • 2
    @Freiheit RJ45 serial connectors are *very* common on enterprise network gear. My (freshly bought) Ubiquiti EdgeRouter Lite has an RJ45 serial connector. – Eric Brown Dec 06 '17 at 21:54
  • 1
    @chrylis, well, if you trust Wikipedia, [that's technically _not_ an RJ45](https://en.wikipedia.org/wiki/Registered_jack#RJ45), but just a quite similar-looking modular connector. – ilkkachu Dec 07 '17 at 16:13
  • 1
    @Goufalite That's way too real. I tried debugging a wireless issue of a client through the phone once. Turned out that the client had a wireless usb dongle plugged in to the RJ-45 port. Needless to say I was stunned. – siebz0r Dec 08 '17 at 08:27

2 Answers2

107

That is a port for a UPS Communications Cable Simple Signalling - USB to RJ45 cable for connecting to a computer. The cable is included with many compatible APC devices.

UPS Communications Cable Simple Signalling - USB to RJ45 cable

Steven
  • 27,531
  • 11
  • 97
  • 118
  • 1
    Comments are not for extended discussion; this conversation has been [moved to chat](http://chat.stackexchange.com/rooms/69776/discussion-on-answer-by-steven-identify-an-unusual-usb-port). – Journeyman Geek Dec 06 '17 at 00:26
65

That is an APC cable by Schneider Electric cable P/N AP9827

https://www.amazon.com/APC-AP9827-USB-cable/dp/B0002WYJSU

It looks like half an Ethernet cable with just four wires in 1 3 5 6 enter image description here

APC's user manual from one type of UPS is downloadable at: http://www.apc.com/salestools/JGNY-9X784R/JGNY-9X784R_R0_EN.pdf

And an excerpt with that connector is:

enter image description here

123456789123456789123456789
