My front panel audio stopped working, so I removed the panel PCB replaced the 3.5mm audio jack with a new one.

I soldered it myself, and it does not look pretty. So before I attach it to my motherboard, I would like to know if it is OK to (accidentally) short the motherboard's front panel audio or USB headers.

Motherboard Audio Header:

Motherboard Audio Header

Replacement Audio Jack

Replacement Audio Jack

Giacomo1968
  • 53,069
  • 19
  • 162
  • 212
Jack
  • 11
  • 1
  • Do you have a pic of your soldering job? I know you might be embarrassed but the pics you have posted only show the bookends to the issue, and not the core issue. – Giacomo1968 Nov 25 '20 at 20:08
  • I'm assuming that I shorted nearby pins together while soldering them. – Jack Nov 25 '20 at 20:40
  • No; It isn’t ok to short the pins – Ramhound Nov 25 '20 at 20:45
  • *"I shorted nearby pins together while soldering them"* -- Since you shouldn't be soldering a powered board, there is no issue with shorting pins (temporarily). – sawdust Nov 25 '20 at 21:09

1 Answers1

1

That really depends which pins. If you touched the line-level pins or NC (not connected), no issue. If you touched the +5V lines to something else, potentially... depending on what you shorted them to. Use the below image as a guide.

enter image description here

The outcome also very much depends on whether the machine was powered on at the time of the short.

Best case, you shorted 2 line-level pins which is not an issue. Worst case, you put 5V to ground, but it should dissipate through he ground wires into the PSU. There are some other possible outcomes listed here.
