I am researching trying to install an extra SSD on a Latitude E6440, and there seems to be another slot labeled WWAN beneath the slot that's used everywhere I see.

Is that another identical slot? Can I use them both together, and do they both work with an SSD?

This is the slot I see used for this procedure:

enter image description here

This picture shows the other slot underneath:

enter image description here

Ramhound
  • 41,734
  • 35
  • 103
  • 130
WOX GAMER
  • 13
  • 2
  • Page 16: https://dl.dell.com/topicspdf/latitude-e6440-laptop_owners-manual_en-us.pdf – Joep van Steen May 30 '23 at 19:29
  • Page 16 shows the WLAN card, which is different. Page 17 is unhelpful. – WOX GAMER May 30 '23 at 19:34
  • https://www.dell.com/community/Laptops-General-Read-Only/Latitude-E6440-mSATA-support/td-p/4355792 - just doing some googling for you. – Joep van Steen May 30 '23 at 19:40
  • Trust me I had been googling before asking, also I scoured the Dell website but never stumbled upon that forum post. From what the guy said, the lower slot only works with a network card and the upper one is normal mSATA. – WOX GAMER May 31 '23 at 09:15

2 Answers2

1

Both this slots are (universal) PCIe M.2. Theoretically, both of them are compatible [with SSD of such kind], but to make sure it is better to rearrange the working SSD from one to the other and check if it will work (detected by the system)

Sergey
  • 232
  • 1
  • 4
0

Are you sure there are 2 WWAN slots? 1 is for a cellular Internet Card. Fairly common on some Lenovo machines.

That will not be the same (at all) as an SSD slot.

John
  • 46,167
  • 4
  • 33
  • 54
  • The upper one is called WWAN in the Dell [guide](https://www.dell.com/support/kbdoc/en-us/000124676/latitude-e6440-removal-guide-for-memory-wifi-card-wwan-card-and-coin-cell-battery). The lower one I haven't seen mentioned anywhere. – WOX GAMER May 30 '23 at 19:36
  • That slot is for a cellular Internet card as I mentioned. – John May 31 '23 at 00:43
  • Not helpful that they are never distinguished in any documentation. – WOX GAMER May 31 '23 at 09:20
