I have a Dell Precision M4700 laptop. But I can't figure out what this thing in the picture is. Can somebody help?

Dell Precision M4700

bwDraco
  • 45,747
  • 43
  • 165
  • 205
Mayank
  • 2,158
  • 6
  • 22
  • 27
  • According to the [Dell site](http://www.dell.com/us/business/p/precision-m4700/pd) of your model it should have Mobile Broadband & GPS and the picture you're seeing is most likely to indicate that – Darius Jun 22 '13 at 18:56
  • 1
    For the same of search engine friendlyness, I'd like to point out that looks like a rectangle or card with a radio symbol around it and that it dosen't look much like the official near field communication symbol on the wikipedia article. – Journeyman Geek Jun 23 '13 at 10:51

3 Answers3

22

This icon indicates an NFC reader. It is used for two-factor authentication using a contactless smart card and a password.

This means you can log into your computer by both tapping a smart card to the icon and typing your password, offering added security. This is often used in corporate environments where high security is required.

For more information, see page 79 (PDF page 50) of this Dell document. The reader supports several NFC protocols, including iCLASS and MIFARE.

bwDraco
  • 45,747
  • 43
  • 165
  • 205
  • 2
    I just tapped my smartphone which has NFC. Nothing happened. :( – Mayank Jun 22 '13 at 19:00
  • The reader might not be enabled continuously. – bwDraco Jun 22 '13 at 19:01
  • 1
    I don't think it is NFC. No such thing appears in Device Manager. – Mayank Jun 22 '13 at 19:02
  • Look for a smart card reader in Device Manager. Perhaps it is disabled at the BIOS... – bwDraco Jun 22 '13 at 19:03
  • I do use Smart Card Reader on it which is a slot on the left side in which the card slides in. It is "Broadcom usbccid Smartcard Reader (WUDF)". Another is Dell Control Vault with fingerprint swipe sensor which is visible on the right. I will test with my smart card on this logo and update this thread. – Mayank Jun 22 '13 at 19:11
  • 2
    That's for a different type of smart card than what you're using. You're using a *contact* smart card. The NFC reader is for *contactless* smart cards. – bwDraco Jun 22 '13 at 19:15
  • Many laptop manufacturers use the same case for different model laptops, even if they don't have all the features. My Dell has a bunch of labeled but non-functional ports on the sides for features that were not included on this model, basically dummy ports which I could presumably upgrade. – Darrel Hoffman Jun 23 '13 at 03:06
  • As far as I know the Dell notebooks do not have NFC integrated. It is a contactless smart card reader. See also the other answers. – pabouk - Ukraine stay strong Jan 23 '14 at 10:04
  • It's built on the same NFC protocols nonetheless. – bwDraco Jan 27 '14 at 17:53
  • I was hoping it was wireless charging.... But yea.. that would be to convenient. ;) – Piotr Kula Oct 19 '16 at 09:46
5

It appears to be the contactless smart card reader. It should appear as "Broadcom Unified Security Hub CV w/fingerprint sensor" in the Device Manager.

wnrph
  • 3,633
  • 1
  • 26
  • 39
4

It's a Contactless Smart Card reader, according to the manual (see p81). No word on NFC in the manual.

Thomas D
  • 141
  • 4
