I have a pair of DDR3 SODIMM RAM modules in my laptop, and I want to replace the 2GB for a 4GB that is compatible. So far I haven't been able to find an exact match but I found a very similar with a PC3L label instead of PC3. Can they work together?

My DDR3 SODIMM RAM:

enter image description here

Memory module in question:

enter image description here

Installed RAM: 4GB DDR3 2Rx8 PC3 12800S 11 10 F2

Matching RAM: 4GB DDR3 2Rx8 PC3L 12800S 11 10 F3

Laptop: Toshiba Satellite L645D-S4036

fixer1234
  • 27,064
  • 61
  • 75
  • 116
Gabriel
  • 2,860
  • 11
  • 36
  • 51

1 Answers1

58

What you are referring to is related to DDR3 memory standardization.

  • DDR3 or PC3 is the Standard Voltage memory module that operates at 1.50V (JEDEC compliant)
  • DDR3L or PC3L is the Low Voltage memory module that operates at 1.35V (JEDEC compliant)
  • DDR3U or PC3U is the Ultra Low Voltage memory module that operates at 1.25V (still not JEDEC compliant)

Most, if not all PC3L modules can support 1.50V operation, so there shouldn't be any issues in your case

Edit. I've just checked in the Samsung catalogue, and I can confirm now that your Samsung M471B5273CH0 PC3L is dual voltage module. Enjoy :)

enter image description here

Nikola Dimitrijevic
  • 4,095
  • 1
  • 18
  • 28
  • 1
    Is the converse true? My laptop has 4GB "PC3L" - 12800S RAM. Can I install 4GB "PC3" 12800S RAM to upgrade to 8GB ? – Navigator Jul 10 '14 at 08:02
  • Yes without any issue if your laptop mobbo supports the 1.5V on memory – Nikola Dimitrijevic Jul 10 '14 at 15:49
  • There's this excellent article on memory compatibility at Dell http://www.dell.com/support/article/us/en/19/SLN153768/en – Marcin Gil Jul 20 '16 at 06:29
  • 1
    @Navigator Did your PC3 ram work fine together with PC3L ram? I am using a hp laptop and it came with 1Rx8 PC3L ram installed; I just ordered a 1Rx8 PC3 ram and hope they will be compatible with each other. – dragonfly02 Jan 22 '18 at 10:01
  • @stt106 Did yours work? I'm finding myself at the same situation :) – David Refoua Mar 13 '19 at 14:15
  • 1
    @DavidRefoua no, it didn't work. In the end I think it's impossible to tell by yourself whether a ram is going to work on your laptop/pc. I had to use a website that sells ram and only buy the ones it says it will definitely work on my pc. – dragonfly02 Mar 14 '19 at 14:50
  • @stt106 Thanks for the update! I think that this is the type of information that should be covered somewhere in the manufacturer's documentation. Sadly those barely contain any information that could be practically useful. I guess it more or less comes down to trial and error. – David Refoua Mar 14 '19 at 15:45
  • Have several laptops of identical model, re-purposed them all. One gave an error on boot saying it had unsupported DDR3. Checked the RAM sticks/cards and discovered that the one that doesn't work is the only one that is PC3 rather than PC3L. – wolfsshield May 30 '19 at 18:11
  • "Most, if not all PC3L modules can support 1.50V operation, so there shouldn't be any issues in your case" - You're implying that using them together will result in the DDR3L module not running at 1.35V? – Paul Mar 24 '23 at 17:10
