I am trying to convert the following image to a vector outline so I can cut it on a laser.

I use corel draw to print to our laser cutter. If the line is hairline then corel will cut out the item.

Normally I get everything as a autocad file so this is stumping me. I really do not want to try and trace this.


RedGrittyBrick
  • 81,981
  • 20
  • 135
  • 205
birdman3131
  • 852
  • 6
  • 15
  • Many image editing programs will have an edge-detection filter. Its a long time since I used Corel Draw but I am sure it had (or came with) a tool to automatically trace outlines from bitmap images – RedGrittyBrick Feb 16 '15 at 16:32
  • Does [Click `Bitmap` menu ⇒ `Trace Bitmap` ⇒ `Detailed Logo`](http://www.corel.com/content/pdf/cgsx3/tutorials/dr_4.pdf) not work with this image? – RedGrittyBrick Feb 16 '15 at 16:45
  • This short guide might help: https://melab.wikischolars.columbia.edu/file/view/How+to+Create+Hairline+Outline+in+Corel+Draw+for+the+Laser+Cutter.pdf – Philip Allgaier Feb 16 '15 at 16:46
  • @PhilipAllgaier That worked enough to figure the rest out. Thanks. – birdman3131 Feb 17 '15 at 14:12

1 Answers1

0

You mentioned you had AutoCAD. Within Autocad, you can import an image, put it as a background image and then trace over top. There might be an auto detect feature in AutoCAD too if I am not mistaken.

Eric F
  • 3,319
  • 5
  • 24
  • 42
