I want to update a BIOS to a new version. While the update process executes, was given this error:

The battery must be charged above 10 before the system bios can be flashed

image of the error message

My equipment is:

    Laptop DELL Inspiron N5110
    Windows Technical Preview
    Processor:   Intel I7 – 2630QM @2.00GHz
    RAM      :   4 GB
    OS       :   64-bit

The laptop's battery is dead. Is there a way to bypass this step?

RockPaperLz- Mask it or Casket
  • 7,741
  • 30
  • 73
  • 122
ozkank
  • 351
  • 1
  • 2
  • 10
  • 2
    I don't think so. The warning is to prevent a power loss while the bios is being flashed, which I guess could lead to a bricked computer. – DavidPostill Feb 18 '15 at 16:56
  • Unless Dell provide another method outside of Windows to update the BIOS you are at the mercy of Dell's program. – Ramhound Feb 18 '15 at 16:58
  • Look no more. Dell documentation has already covered this problem. See https://www.dell.com/support/kbdoc/en-us/000134938/forcing-a-bios-update-without-the-ac-adapter-attached-on-a-dell-laptop – Pavindu Apr 29 '21 at 01:59

5 Answers5

34

With Dell BIOS updates you can run the BIOS update exe at the command line and add /forceit:

  • Copy the BIOS update .exe file locally on to your PC
  • Open the command prompt as the admininstrator
  • Navigate to the location of the .exe file
  • Type the name of the .exe file and add /forceit to the end eg: E7440A13.exe /forceit
  • Press Enter

The update should start and ignore the lack of a battery @ 10% charge.

Pavindu
  • 107
  • 5
Dimblefeck
  • 707
  • 6
  • 15
  • Can you give me further detail? – ozkank Feb 18 '15 at 17:20
  • 4
    Copy the BIOS update exe file locally on to your PC, open the command prompt, navigate to the location of the exe file and type the name of the exe file and add /forceit to the end eg: **E7440A13.exe /forceit** press enter and the update should start and ignore the lack of a battery @ 10% charge. – Dimblefeck Feb 18 '15 at 17:26
  • 1
    Try it again but use an elevated command prompt (run as administrator). – CharlieRB Feb 18 '15 at 19:08
  • Sorry to hear that. I have to say I've only worked with Dell Latitude C, D & E series & Dell Precision laptops, not the Inspirons and whilst working with them the need to flash the BIOS on a system with a bad battery has been rare but it did work for me with them. Perhaps the Inspiron's use a different BIOS flash method that does not have the forceit option avialable to it. – Dimblefeck Feb 19 '15 at 09:09
  • It worked fine for me on an e6400 – Dark Dec 28 '15 at 18:10
  • 1
    Shows "Unkown command" for me – Lucas Bustamante Jun 07 '19 at 04:52
  • The command doesn't work because you are supposed to add 'start' before the command. "start E7440A13.exe /forceit" without the quotation mark. – Hearty Dec 30 '19 at 17:27
  • When I added /forceit I'm getting an error in WinFlash - "Parameters are not valid". I have an Asus btw. – Neerkoli Apr 18 '21 at 15:39
  • 2
    This BIOS update is for Dell systems, probably why you are getting that message. – Dimblefeck Apr 19 '21 at 06:04
12

Update: Oh yeah, and do make sure to use the latest upgrade. In your error screenshot above I can see you’re using an older update.

I suggest you use Rufus to create a MS-DOS-bootable USB drive and then run the upgrade from DOS. Of course, you’ll have to copy the update to the USB drive as well.

Rufus settings should be set as following:

enter image description here

Then, after booting from the USB drive, simply start the flash program:

enter image description here

Then, follow the steps the flash program walks you through.

Like the others said, you might want to try the /ForceIt parameter. With a slash, not a dash. ;)

Daniel B
  • 60,360
  • 9
  • 122
  • 163
  • 2
    Thanks, it worked like a charm ! Rufus is the simplest tool I've found so far to create a FreeDOS live USB stick :-) Also, since I had **no battery at all** in my **Dell Inspiron 1525**, I had to use the `/forceit` parameter to bypass the warning. – breversa Mar 11 '20 at 11:45
  • Also successful with Easy2boot with FreeDOS. – Ygor Montenegro May 19 '21 at 15:33
9

I have found a solution to your problem here.

  1. Download the latest firmware from the Dell support
  2. Save the exe and create a shortcut with the following parameter: " /writehdrfile"
  3. Start the created shortcut and it will create a n5110a11.hdr file rename the file to N5110.hdr
  4. Create a shortcut exe file with the following parameter: " /writeromfile"
  5. Start the created shortcut and it will create a n5110a11.rom file rename the file to DQ15A11.rom
  6. Copy both file N5110.hdr and DQ15A11.rom to a FAT formatted pendrive's root folder
  7. Remove the charger and Battery from the laptop
  8. Plug In the pendrive
  9. Press & hold END
  10. Connect the charger (still hold END)
  11. The notebook starts automatically and shows the recovery screen
  12. Press enter and wait until finish the flashing
  13. Press esc to restart
  14. Hopefully problem solved
DavidPostill
  • 153,128
  • 77
  • 353
  • 394
Syed Ali Naqi
  • 191
  • 1
  • 2
  • Please read [How to reference material written by others](https://superuser.com/help/referencing). You must block quote text that has been written by some else. See [Markdown help](https://superuser.com/editing-help). I've fixed it for you this time, but please pay attention to this in future. – DavidPostill Apr 26 '17 at 22:29
  • Job Done, thanks for sharing this awesome BIOS update.. worked a treat where a faulty battery prevented an update via Windows. – user283868 May 23 '18 at 17:14
  • What's with the file names if I have a different Dell BIOS update? Do I still change it to DQ15A11.rom? – hoppy Sep 02 '19 at 14:54
  • @hoppy I ran my different Dell laptop's bios XXX.exe with `/writehdrfile` then `/writeromfile` which created two XXX.rom and XXX.hdr files. Then I did the USB bootup with them in the root as above and it worked. – spcsLrg Dec 12 '22 at 13:06
5

Just got through this "upgrade bios without battery" hell on my Acer E11.

The following worked for me:

  • Download the BIOS update from Acer site (ZHK116.EXE)
  • Run the downloaded file, you will get an error like "No battery" or "Low battery", stay on the error dialogue (!)
  • Navigate to your current users temp directory (e.g. Users//AppData/Local/Temp), there should be somewhere a temporary directory containing the extracted files from the EXE file (for me it was 7zS4A88.tmp)
  • Save the contents of that temp directory somewhere (you can then close the error dialogue, the temp files will be removed)
  • Open the file platform.ini with a text editor and search for the key "AC_Adapter"
  • Change parameter BatteryCheck from 1 to 0 or just leave it empty (this disables battery check during BIOS update preparation!), save the file
  • Run InsydeFlash.exe in the same directory
  • That's it, bios update should start now

Source http://serverissue.com/issue/cnvj-how-to-upgrade-uefi-bios-without-battery-in-acer-laptop

it solved my battery not charging issue work beautifully..

DavidPostill
  • 153,128
  • 77
  • 353
  • 394
amoniak
  • 51
  • 1
  • 1
  • As of the Precision 7510, the temp dir does not have any files there nor C:\windows\temp – Kevin Jan 12 '18 at 22:40
  • The self-extracting updater for my BIOS contained a `platforms.ini` instead of `platform.ini`. If I made the above changes to `platforms.ini` they would get reverted after running `InsydeFlash.exe`, which would still prompt for "The AC adapter and battery must be plugged in ...". After renaming the modified `platforms.ini` to `platform.ini` the `InsydeFlash` utility could proceed without the prompt. – Lance U. Matthews Jun 28 '23 at 21:37
1

I had a Dell Latitude 13 (win 10 x64) which I wanted to update the bios to A02. I tried most of the ways in the forums, which did not work. This is the way I managed to do it using Hiren boot disk.

Download file from Dell.

Download Hiren Boot Disk and create Hiren Boot disk on USB (Google this if you need to)

Copy Dell file to HBD USB

Enter Bios of latitude by pressing F2 key at startup. Enable "start up" from USB and disable all other startup options. Save and close machine.

Insert HBD on USB stick, start computer, boot from the XP option that comes up.

Find the dell file on the USB stick, copy to XP desktop.

Open CMD and using CD.. change to desktop. In the cmd box type "Dell file name" /forceit.

A box open up with option of updating Bios etc.

Minimize CMD box.

Click yes to update Bios. I cant remember if there was another box confirming update but if there was I confirmed.

Left it for a minute - nothing seemed to be happening. Manually rebooted machine.

On the next reboot Bios update started and completed.

After HBD options came up, opened XP and shut down normally.

Went into Bios, reenabled boot option I had previously disabled.

Machine booted into win 10 x64 with new bios.

Problem fixed.

Hope this works for you, try at your own risk.
