possible to have two Y axes and two X axes on same chart

Question

Is it possible to have a chart with

all on same chart?

A chart no, a scatter plot... maybe (not sure about the top X axis though). A better question is why do you want to do that? — Doktoro Reichard, Oct 07 '13 at 21:52
You can have two Y axes on the same graph. Two X axes are not allowed. — , Oct 08 '13 at 07:12
see also http://superuser.com/questions/188064/excel-chart-with-two-x-axes-horizontal-possible?rq=1 — Andi Mohr, Oct 30 '13 at 10:38

score 6 · Answer 1 · edited Oct 30 '13 at 11:20

6

If I have understand well you have two different datasets to compare on the same chart.

If so

You can make your XY chart with both dataset.
Then double click on one series, and on the Axis tab, select Secondary. It appears a secondary Y axis.
Select "Chart Manu/Chart Options/Axes tab", uncheck the secondary Y box, and check the secondary X box.

Example showing two X and Y axes

edited Oct 30 '13 at 11:20

Andi Mohr

answered Oct 17 '13 at 16:50

Ale

1

@Loretta I think you can mark this question as solved – Ale Oct 06 '14 at 16:13
